Radian - Flight Controller
Introducing the Radian Flight Controller, a premier flight control system designed for seamless compatibility with ArduPilot, PX4 and Betaflight firmware and with full Pixhawk standard compatibility. Engineered for superior performance and versatility, the Radian Flight Controller is the perfect solution for a broad spectrum of UAV applications, from recreational drones to complex commercial and industrial operations.
Quick Processing
Trusted Delivery
Secure payment
Specifications
Mounting Holes
Dimensions
Weight
Input Voltage
Advanced Sensor Suite
The Radian flight controller features a high-performance sensor suite designed for stable and precise flight. It integrates dual 9-axis IMUs, combining gyroscopes, accelerometers, and magnetometers to ensure accurate orientation and movement tracking. A high-resolution barometer is also included for dependable altitude control, enabling smooth flight performance in dynamic environments. This comprehensive sensor setup provides the reliability needed for both hobbyist and professional UAV applications.
Power Redundancy
Engineered for reliability, the Radian supports dual power inputs with built-in redundancy to safeguard against power failure mid-flight. Its integrated power management system includes protection circuits that automatically switch to a backup power source if the primary input is compromised. This robust design ensures continuous operation, even under demanding conditions, and minimizes the risk of in-flight power loss for mission-critical use.
Rich Interface
With a wide range of connectivity options, the Radian is ready to integrate into diverse UAV systems. It includes multiple UART, I2C, SPI, CAN, and PWM ports, allowing seamless communication with external devices like GPS modules, cameras, telemetry radios, and motor controllers. Its adherence to the Pixhawk connector standard ensures compatibility and ease of integration, making the Radian a versatile core for any drone platform.
Product details
Key Features
- Dual Firmware Compatibility: The Radian supports both ArduPilot and PX4 firmware, providing the flexibility to select and switch between two leading autopilot platforms to best suit your project requirements.
- Advanced Sensor Suite: Equipped with dual 9-axis IMUs (gyroscope, accelerometer, magnetometer), a high-resolution barometer. in addition, all sensors and dual redundant. the Radian offers accurate and stable navigation in various flight conditions.
- Extensive Connectivity Options: With multiple I/O ports including UART, I2C, SPI, CAN, and PWM, the Radian supports a wide array of peripherals such as cameras, gimbals, telemetry modules, and additional sensors.
- Robust Power Management: Featuring an integrated power management system with redundant power inputs and protection circuits, the Radian ensures reliable operation even in demanding environments while supporting up to dual 14S input.
- Compact and Lightweight Design: The Radian's optimized PCB layout and compact form factor make it suitable for a variety of UAV platforms, including multirotors, fixed-wing aircraft, and VTOLs.
- User-Friendly Setup: The Radian comes with pre-configured settings and detailed documentation for a quick and easy setup process, supported by a wealth of community resources for troubleshooting and customization.
Specifications
- Processor Variants: STM32F405RG (Cortex-M4 @ 168 MHz, 1 MB Flash, 192 KB SRAM), STM32H743 (Cortex-M7 @ 480 MHz, 2 MB Flash, 1 MB SRAM)
- IMUs: Bosch BMI270, TDK ICM42688P
- Barometers: Bosch BMP280, ST LPS22HBTR
- Compasses: Bosch BMM150, ST LIS3MDL
- Power Input: Dual redundant inputs up to 60 V (3S–14S LiPo), integrated dual eFuse, voltage sensing, onboard DC-DC conversion
- Mounting Holes: M3 (30.5 X 30.5 mm)
- Dimensions: 38 X 46 mm
- Weight: 19 g
- Input Voltage: 7-60 V
Product Manual
Included in the Box
1x Radian Flight Controller Unit
1x Radian Carrier
1x Cable Kit
1x FCU Plastic Enclosure
